Custom Double-Sided VHB Foam Tape Parts
Precision die-cut acrylic foam tape parts for clean, high-bond mounting of trims, panels and dissimilar materials.
Custom double-sided acrylic foam tape shapes that replace screws and liquid adhesive in permanent bonding assemblies.
Engineered Custom Double-Sided VHB Foam Tape Parts
Acrylic foam tape is converted into exact mounting patterns with holes, split liners and complex outlines. Its viscoelastic core conforms to minor surface irregularities while the adhesive creates a durable bond over a broad area.
Material approach
Acrylic foam distributes stress across the bonded area and can bond many coated, painted and high-surface-energy substrates.
Key features
- High-strength acrylic bonding
- die-cut geometry
- vibration damping
- gap conformability
- liner tabs for automated or manual application.
Custom Specifications
Typical values for reference only. Final material grade, tolerance and dimensional capability are confirmed after drawing review.
| Material | Acrylic foam tape with acrylic adhesive |
|---|---|
| Thickness range | 0.4-3.0 mm |
| Typical thickness | 1.1-2.0 mm |
| Size range | 5 mm features to 1,200 x 900 mm sheets |
| Temperature range | -40 to 150 C; grade-dependent |
| Hardness range | Not typically specified by Shore hardness; use tape grade and dynamic stiffness |
| Tolerance | Typically +/-0.20 mm die-cut profile |
| Standards | Material documentation and automotive-grade specifications available by selected tape series. |
MATERIAL SELECTION
Double-Sided VHB Foam Tape Parts Material Comparison
Use this as a starting point only; the selected grade and construction are confirmed against the drawing and application.
| Material | Primary strength | Selection focus | Best fit |
|---|---|---|---|
| Acrylic foam tape grades selected for substrate | Acrylic foam distributes stress across the bonded area and can bond many coated, painted and high-surface-energy substrates. | Choose a thinner grade for firm flat surfaces and a thicker foam grade when the joint needs greater conformability or vibration isolation. | Automotive trims, signage, display mounting, nameplates, access panels, electronic housings and decorative assemblies. |
| thickness | Viscoelastic foam core, high shear adhesion, weather resistance and controlled thickness for bond-line consistency. | Choose a thinner grade for firm flat surfaces and a thicker foam grade when the joint needs greater conformability or vibration isolation. | Automotive trims, signage, display mounting, nameplates, access panels, electronic housings and decorative assemblies. |
| temperature and bond strength requirements. | Viscoelastic foam core, high shear adhesion, weather resistance and controlled thickness for bond-line consistency. | Choose a thinner grade for firm flat surfaces and a thicker foam grade when the joint needs greater conformability or vibration isolation. | Automotive trims, signage, display mounting, nameplates, access panels, electronic housings and decorative assemblies. |
PRODUCT EXAMPLES
Custom Part Gallery
CONVERTING OPTIONS
Manufacturing & Finish Options
Bond strength develops over time; substrate cleaning, pressure and dwell time are critical to a reliable joint.
Custom Die Cutting
A repeatable route for defined profiles after tooling and project review.
Custom Die Cutting →Kiss Cutting
Liner-retained parts and pull-tab layouts for placement workflows.
Kiss Cutting →Adhesive Backing
PSA and liner constructions selected for the mating surface and assembly method.
Adhesive Backing →Industrial Laminating
Layered material constructions developed as a complete assembly.
Industrial Laminating →DESIGN REVIEW
Engineering Guide
Practical points to include when selecting foam and preparing a drawing for review.
Geometry and thickness
Maximize bonded area and design against peel; use rounded corners and maintain a continuous load path where possible.
Assembly performance
Validate with actual substrates, coatings and service temperature because surface energy and joint geometry drive bond performance.
Production route
Bond strength develops over time; substrate cleaning, pressure and dwell time are critical to a reliable joint.
Applications / Where It Fits
Custom double-sided acrylic foam tape shapes that replace screws and liquid adhesive in permanent bonding assemblies. The final specification is established around the drawing and operating requirements.
When This Part May Not Be the Best Choice
Unprepared low-surface-energy plastics, joints with constant peel loading, or assemblies that require easy removal and reuse.
PROJECT DELIVERY
Manufacturing Capabilities
Available options are confirmed against the selected material, drawing and order requirements.
| Capability | Options |
|---|---|
| Manufacturing process | Rotary die cutting, flatbed die cutting, laser-assisted converting and liner lamination |
| Adhesive options | Integrated double-sided acrylic adhesive; custom liner and finger-lift options. |
| Surface options | Black, grey or white foam grades; custom die-cut liner geometry. |
| Custom options | Outline, hole pattern, thickness, split liner, pull tab, rolls, sheets and serialized kit packaging. |
| Standards | Material documentation and automotive-grade specifications available by selected tape series. |
Drawing Requirements
Recommended drawing formats
Please include
- mating substrates
- bond area
- service temperature
- peel exposure and liner configuration
For a precise custom double-sided vhb foam tape parts quotation, provide mating substrates, bond area, service temperature, peel exposure and liner configuration.
Frequently Asked Questions
Does VHB tape replace screws?
In a properly designed and validated bond, acrylic foam tape can replace many screws, rivets and liquid adhesives.
How should the surface be prepared?
Remove oils and dust, then follow the selected tape supplier preparation guidance; primers may be used for difficult substrates.
Can the tape be supplied with pull tabs?
Yes. Extended liners, split liners and finger lifts can be die cut to simplify installation.
Is it suitable for outdoor use?
Many acrylic foam grades are designed for weather and UV exposure, subject to the selected series and joint design.
What should a drawing include for custom double-sided vhb foam tape parts?
Include mating substrates, bond area, service temperature, peel exposure and liner configuration.
Can custom double-sided vhb foam tape parts be supplied for production assembly?
Yes. Bond strength develops over time; substrate cleaning, pressure and dwell time are critical to a reliable joint. Delivery format, liner configuration and packaging are specified for the assembly workflow.
How is the right custom double-sided vhb foam tape parts construction selected?
Choose a thinner grade for firm flat surfaces and a thicker foam grade when the joint needs greater conformability or vibration isolation. The drawing and operating conditions establish the final construction.
